This tutorial of Robo India explains how to install driver of CH340 USB to serial converter.

With the advantage of USB port, users have the capability to utilize the peripheral with serial port interface in an easy-to-use environment such as plug and play & hot swap function. This single chip is designed for ideal connections to Cellular Phone, Digital Camera, Modems or ISDN terminal adapters with over 1Mbps data transfer rate.
This direct connect USB TTL adapter works with Windows 10 and earlier or Mac OS 10 X and Linux. Serial UART cable and its 6-pin TTL connector as a regular serial device connection while the FTDI chip handles USB protocol.

Ans: USB-Serial devices support LVTTL IO levels for Inputs only. CMOS IO level is supported for both Inputs and Outputs. Do USB-Serial devices require external 1.5K pull up resistor on USBDP line? Ans: No, USB-Serial devices don't require external 1.5K pull up resistor on USBDP line. The pull-up resistor is integrated inside the chip.

1. Introduction:

Download windows driver from here .

CH340 windows driver

2. Automatic installation:

If you are connected to internet, just plug CH340 USB to serial converter to your computer, windows will detect and download driver. You will see following message on successful installation. CH340 is installed on comport 23.

Arduino Nano Board with prototype board.

Buy on Amazon

Buy on Robo India

3. Manual installation

Follow following instruction to manually install driver of CH340.

3.1 Download driver from the link provided above in this tutorial.

3.2 Go to start menu.

3.3 Right click on My Computer.

3.5 Click on Properties

3.6 Select Device Manager form left control panel

3.7 Expand USB options available

3.8 Right click on CH340

3.9 Select Update driver

3.10 Select browse option
